| 型號(hào) |
排氣壓力
MPa
|
容積流量
m3/min
|
電機(jī)功率
kW
|
噪音
dB(A)
|
重量
kg
|
出口尺寸 |
外形尺寸
LxWxH mm
|
|
| Min | Max | |||||||
| LU45-7GP IVR | 0.7 | 1.38 | 7.32 | 45 | 69 | 910 | G11/2 | 1720X980X1600 |
| LU45-8GP IVR | 0.8 | 1.38 | 7.32 | |||||
| LU45-10GP IVR | 1.0 | 1.26 | 6.78 | |||||
| LU45-13GP IVR | 1.3 | 1.02 | 5.76 | |||||
| LU55-7GP IVR | 0.7 | 1.44 | 8.94 | 55 | 72 | 1300 | G2 | 1950X1060X1600 |
| LU55-8GP IVR | 0.8 | 1.44 | 8.94 | |||||
| LU55-10GP IVR | 1.0 | 1.32 | 8.28 | |||||
| LU55-13GP IVR | 1.3 | 1.02 | 7.14 | |||||
| LU75-7GP IVR | 0.7 | 2.16 | 11.88 | 75 | 73 | 1360 | G2 | 1950X1060X1600 |
| LU75-8GP IVR | 0.8 | 2.16 | 11.88 | |||||
| LU75-10GP IVR | 1.0 | 1.86 | 10.68 | |||||
| LU75-13GP IVR | 1.3 | 1.56 | 9.42 | |||||
| LU90-7GP IVR | 0.7 | 2.70 | 15.12 | 90 | 73 | 1650 | G2 | 2260X1060X1600 |
| LU90-8GP IVR | 0.8 | 2.64 | 15.12 | |||||
| LU90-10GP IVR | 1.0 | 2.22 | 13.44 | |||||
| LU90-13GP IVR | 1.3 | 1.62 | 10.98 | |||||
